7075 T652 Aluminum Forging Plate

Chemical composition of 7075 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.4% max
• Ferrum (Fe): 0.5% max
• Copper (Cu): 1.2-2.0%
• Manganese (Mn): 0.3% max
• Magnesium (Mg): 2.1-2.9%
• Chromium (Cr): 0.18-0.28%
• Zinc (Zn): 5.1-6.1%
• Titanium (Ti): 0.2% max
• Other elements: Each 0.05% max, Total 0.15% max


  ---

Typical mechanical properties of 7075 T652 aluminum

• Tensile strength: 540 MPa
• Yield strength: 470MPa
• Elongation: 7%
• Hardness (Brinell): 155 HB

(The values are typical or min values,for reference only.)

---

7075 aluminum sheet plate application

7075 aluminum is one of the strongest aluminum alloys.with corrosion resistance,durability,and good Machinability.

7075 aluminum sheet plate use for：

Aerospace industry:  aircraft fuselages, wings, and other structural components.

Military equipment: weapons and armor, because of its high strength and durability.

High-stress applications: bicycle frames, rock climbing equipment, and automotive parts.

Sporting goods: golf heads, ski poles baseball bats and tennis rackets.

3C products,tooling and machining.

---

Aluminum 7075 T6 VS T652 / Why choose 7075 T652

In short，T652=T6+Forging（stress relief）

When the thickness of the 7075 T6 aluminum plate reaches about 250mm, due to the limited rolling force of the roller, the internal organization is not fully extended, resulting in the internal is still in a loose state, affecting the material properties.

Forging can make the internal organization to be fully extended, improve product performance. In addition, after forging, flaw detection will be conducted to reduce the probability of bad problems such as trachoma and porosity.7075 T652 aluminum plate involves a stress relief treatment after the initial aging process. This results in a lower level of residual stress, which can improve resistance to stress corrosion cracking and other forms of metal fatigue.

---
