7075 T6 Aluminum Sheet Plate

Chemical composition of 7075 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.4% max
• Ferrum (Fe): 0.5% max
• Copper (Cu): 1.2-2.0%
• Manganese (Mn): 0.3% max
• Magnesium (Mg): 2.1-2.9%
• Chromium (Cr): 0.18-0.28%
• Zinc (Zn): 5.1-6.1%
• Titanium (Ti): 0.2% max
• Other elements: Each 0.05% max, Total 0.15% max


  ---

Typical mechanical properties of 7075 T6 aluminum

• Tensile strength: 540 MPa
• Yield strength: 470MPa
• Elongation: 8%
• Hardness (Brinell): 155 HB

(The values are typical or min values,for reference only.)

---

7075 aluminum sheet plate application

7075 aluminum is one of the strongest aluminum alloys.with corrosion resistance,durability,and good Machinability.

Aluminum plate 7075 T6 use for：：

Aerospace industry:  aircraft fuselages, wings, and other structural components.

Military equipment: weapons and armor, because of its high strength and durability.

High-stress applications: bicycle frames, rock climbing equipment, and automotive parts.

Sporting goods: golf heads, ski poles baseball bats and tennis rackets.

3C products,tooling and machining.

Overall, 7075 aluminum plate is a versatile material that offers high strength and toughness, making it suitable for a wide range of applications.

---
