5083 Aluminum Round bar

Chemical composition of 5083 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.4%
• Ferrum (Fe): 0.4% max
• Copper (Cu): 0.1%
• Manganese (Mn): 0.4-1.0% max
• Magnesium (Mg): 4.0-4.9%
• Zinc (Zn): 0.25% max
• Titanium (Ti): 0.15% max
• Other elements: Each 0.05% max, Total 0.15% max


  ---

Typical mechanical properties of 5083 H112 aluminum

For aluminum rod 5083 T4: φ50-100mm

• Tensile strength: ≥270 MPa
• Yield strength: ≥125 MPa
• Elongation: ≥12%
• Hardness (Brinell): 81 HB

(The values are typical or min values,for reference only.)

---

5083 aluminum round bar application

5083 aluminum plate has high strength, corrosion resistance and light weight. The content of magnesium in the trace elements of 5083 is higher. In the non-heat treatment alloy, the hardness is higher. Good seawater resistance and low temperature, suitable for welding structures with high corrosion resistance.

5083 Aluminum sheet Suitable for ships and boats,5083 aluminum plate is used for vehicles: aluminum alloy tank car body/tank, automobile fuel tank, air storage tank, bus skin, C82 coal truck, car roof/bottom protection plate, etc.

5083 thick aluminum plate is used for: mould, LNG storage tank, flange material, GIS high voltage switch shell, precision machining, etc.

---
