2017Aluminum Round bar

Chemical composition of 2017 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.2-0.8%
• Ferrum (Fe): 0.7% max
• Copper (Cu): 3..5-4.5%
• Manganese (Mn): 0.4-1.0%
• Magnesium (Mg): 0.4-0.8%
• Chromium (Cr): 0.1% max
• Zinc (Zn): 0.25% max
• Titanium (Ti): 0.15% max
• Other elements: Each 0.05% max, Total 0.1% max


  ---

Typical mechanical properties of 2017 T4 aluminum

For aluminum rod 2017 T4: φ≤120mm

• Tensile strength: ≥345 MPa
• Yield strength: ≥215 MPa
• Elongation: ≥12%
• Hardness (Brinell): 104 HB

(The values are typical or min values,for reference only.)

2017 aluminum round bar application

2017 aluminum rod has High strength, a certain heat resistance, 2017 aluminum rod is usually used in rivets, general machinery parts, aircraft, ships, traffic, building structural parts, transport tools structural parts, propeller components and accessories.
