7050 Aluminum Sheet Plate

Chemical composition of 7050 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.12% max
• Ferrum (Fe): 0.15% max
• Copper (Cu): 2.0-2.6%
• Manganese (Mn): 0.1% max
• Magnesium (Mg): 1.9-2.6%
• Chromium (Cr): 0.04% max
• Zinc (Zn): 5.7-6.7%
• Titanium (Ti): 0.06% max
• Zirconium (Zr):0.08-0.15%
• Other elements: Each 0.05% max, Total 0.15% max


  ---

Typical mechanical properties of 7050 T7451 aluminum

• Tensile strength: 524 MPa
• Yield strength: 469 MPa
• Elongation: 8%
• Hardness (Brinell): 152 HB

(The values are typical or min values,for reference only.)

---

7050 aluminum sheet plate application

7050 aluminum sheet is a very high-strength alloy in the 7xxx series of aluminum alloys,with good corrosion resistance,Good machinability,strong and durable， making it ideal for applications where strength is critical.

---

7050 T7451 aluminum alloy plate use for：

Aerospace applications:  aircraft structures and parts, such as fuselage frames, wing skins, and bulkheads.

Defense applications:  military vehicles and armor plating.

Sporting goods:baseball bats, bicycle frames, and ski poles.

Industrial applications: high-stress components for industrial machinery and equipment.

---
