6061 T6 Aluminum Sheet Plate

Chemical composition of 6061 aluminum alloy

• Aluminum (Al): balance
• Silicon (Si): 0.4-0.8%
• Ferrum (Fe): 0.7% max
• Copper (Cu): 0.15-0.4%
• Manganese (Mn): 0.15% max
• Magnesium (Mg): 0.8-1.2%
• Chromium (Cr): 0.04-0.35%
• Zinc (Zn): 0.25% max
• Titanium (Ti): 0.15% max
• Other elements: Each 0.05% max, Total 0.15% max


  ---

Typical mechanical properties of 6061T6 aluminum

• Tensile strength: 290 MPa
• Yield strength: 240 MPa
• Elongation: 12%
• Hardness (Brinell): 95 HB

(The values are typical or min values,for reference only.)

6061 aluminum sheet plate application

6061 aluminum alloy plate is known for its excellent corrosion resistance, high strength-to-weight ratio, good machinability, and good anodizing performance.

6061 aluminum sheet is one of the most popular use in various applications, including Automatic machine parts, mobile phone card slot, mobile phone case, mold, automobile, precision machining, mold manufacturing, electronics and precision instruments, structural engineering, and so on. 6061 T6 aluminum alloy plate has very high cost performance.
